SYM-5 Tote box type continuous Gamma Irradiator

Home » SYM-5 Tote box type continuous Gamma Irradiator

The SYM-5 tote box type gamma Irradiation plant is ideally suited for medical products, spices, herbal products and other agro products with regular packaging. This is the latest design incorporating many advanced features such as in cell shuffling, split source, batch and continuous mode of operation, automated loading and unloading etc.

Plant specifications:

Maximum source capacity


Tote box specifications

1040mmX630mmX1800mm (capable of handling 470 kg’s of product at a density of 0.4 gms/cc)

Max. Design Throughput

59,000liters / Hr.

Mode of operation

Continuous type plant with product overlap design&in-cell shuffling system.

Key features

  • Product Handling System for cell, and labyrinth with in-cell shuffling feature.
  • Scissor lift assisted loading/ unloading of products.
  • Source Raise system with Hydraulic power pack and mechanical interlock with personnel entry door.
  • DM plant, pool water conditioning and monitoring.
  • Irradiation cell Ventilation System.
  • PLC based control and safety systems with SCADA and HMI interface.
  • Source pass mechanism with a total of 8 passes i.e. 4 in the lower level & 4 in the upper level with a total of 48 irradiation positions.


Dose Range

Production /Hr. @5 MCi

Raw Spices

6 to 14KGy

8 MT/hr.

Herbal products

6 to 14KGy

8 MT/hr.

Medical  Products

25-30 KGy

12 cu Mts/hr.
